HP Compaq dc7100 DT Technical Reference Guide

Technical Reference Guide 361834-002 2-7
System Overview
Figure 2-4 shows the front panel components of the Slim Tower (ST) form factor.
Figure 2-4. HP Compaq dx6100 ST Front View
Item Description Item Decription
1 Micorphone audio In jack 7 Diskette drive activity LED
2 Headphone audio Out jack 8 Diskette media door
3 USB ports 7, 8 9 CD-ROM drive acitvity LED
4 hard drive activity LED 10 Diskette drive eject button
5 Power LED 11 CD-ROM media tray
6 Power button 12 CD-ROM drive open/close button

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
