8. Lift the module to a 45-degree angle (1), and then pull it away to remove it from the socket (2).
Figure 7-53 Removing the WLAN module
To install the WLAN module, reverse the removal procedures.
NOTE: WLAN modules are designed with a notch to prevent incorrect insertion.
WLAN module 73

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq Elite 8300 All-in-One and is the answer not in the manual?

HP Compaq Elite 8300 All-in-One Specifications

General IconGeneral
RAMUp to 16 GB DDR3
NetworkIntegrated Intel 82579LM Gigabit Ethernet
ChipsetIntel Q77 Express
ProcessorIntel Core i5-3470S
Storage128 GB SSD, 256 GB SSD
Display23-inch Full HD (1920 x 1080)
GraphicsIntel HD Graphics 2500
Operating SystemWindows 7 Professional
Optical DriveDVD+/-RW SuperMulti
USB Ports6 x USB 2.0
Wireless802.11a/b/g/n
AudioIntegrated High Definition Audio, Internal Speaker
PortsVGA, DisplayPort, RJ-45, audio in/out
