C–4 Maintenance and Service Guide
Screw Listing
Phillips PM1.5×4.0 Screw Location
Table C-1
Phillips 1.5×4.0 Screw (Continued)
Color Qty. Length Thread
Head
Width
Black 5 4.0 mm 1.5 mm 4.5 mm
Where used:
One screw that secures the memory module compartment cover to the
computer (screw is secured to the cover by a C clip; documented in Section 6.8)
mm
