Screw Listing
Maintenance and Service Guide C–5
Phillips PM2.5×13.0 Screw Location
Table C-2
Phillips PM2.5×13.0 Spring-loaded Hard Drive Retention Screw
Color Qty. Length Thread
Head
Width
Black 1 13.0 mm 2.5 mm 5.5 mm
Where used:
One screw that secures the hard drive to the computer (screw is captured on the
hard drive frame by a C clip; documented in Section 6.4)
mm
