Product Description
Maintenance and Service Guide 1–7
3Battery light ■ Amber: A battery pack is charging.
■ Green: A battery pack is close to full
charge capacity.
■ Blinking amber: A battery pack that is the
only available power source has reached
a low-battery condition. When the battery
reaches a critical low-battery condition,
the battery light blinks more quickly.
■ Off: If the notebook is connected to
external power, the light is turned off
when all batteries in the notebook are
fully charged. If the notebook is not
connected to external power, the light is
turned off until the battery reaches a
low-battery condition.
4 Integrated Drive
Electronics (IDE) drive
light
On: A drive in the hard drive bay or
MultiBay II is being accessed.
5 Infrared port
(full-featured models
only)
Provides wireless communication between
the notebook and an optional
IrDA-compliant device.
6 Display release latch Opens the notebook.
Table 1-1
Front Components
(Continued)
Item Component Function
