HP Compaq NC8230

C–6 Maintenance and Service Guide
Screw Listing
Torx T8M2.0×4.0 Screw Location
Table C-6
Torx T8M2.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Black 16 4.0 mm 2.0 mm 4.5 mm
Where used:
One screw that secures the MultiBay II device to the notebook (documented in
Section 5.6)
mm
