HP Compaq NC8230

Screw Listing
Maintenance and Service Guide C–7
Torx T8M2.0×4.0 Screw Locations
Table C-6
Torx T8M2.0×4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 16 4.0 mm 2.0 mm 4.5 mm
Where used:
5 screws that secure the top cover to the notebook (documented in
Section 5.20)
mm
