HP Compaq NC8230

Screw Listing
Maintenance and Service Guide C–13
Phillips PM1.5×3.0 Screw Location
Table C-7
Phillips PM1.5×3.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Silver 9 1.5 mm 3.0 mm 4.0 mm
Where used:
One screw that secures the TPM security card to the notebook (documented in
Section 5.15)
mm
