HP Compaq NC8230 - Page 209

Screw Listing
Maintenance and Service Guide C–23
Phillips PM2.0×6.0 Screw Location
Table C-14
Phillips PM2.0×6.0 Screw
Color Qty. Length Thread
Head
Width
Silver 1 6.0 mm 2.0 mm 4.0 mm
Where used:
One screw that secures the push button module to the base enclosure
(documented in Section 5.24)
mm
