HP Compaq NC8230 - Page 208

C–22 Maintenance and Service Guide
Screw Listing
Torx T8M2.0×6.0 Screw Locations
Table C-13
Torx T8M2.0×6.0 Screw
Color Qty. Length Thread
Head
Width
Black 7 6.0 mm 2.0 mm 4.5 mm
Where used:
7 screws that secure the system board to the notebook (documented in
Section 5.22)
mm
