Cleaning the Computer Case
Follow all safety precautions in General Cleaning Safety Precautions on page 48 before cleaning the
computer.
To clean the computer case, follow the procedures described below:
To remove light stains or dirt, use plain water with a clean, lint-free cloth or swab.
For stronger stains, use a mild dishwashing liquid diluted with water. Rinse well by wiping it with
a cloth or swab dampened with clear water.
For stubborn stains, use isopropyl (rubbing) alcohol. No rinsing is needed as the alcohol will
evaporate quickly and not leave a residue.
After cleaning, always wipe the unit with a clean, lint-free cloth.
Occasionally clean the air vents on the computer. Lint and other foreign matter can block the vents
and limit the airflow.
Cleaning the Keyboard
Follow all safety precautions in General Cleaning Safety Precautions on page 48 before cleaning the
keyboard.
To clean the tops of the keys or the keyboard body, follow the procedures described in
Cleaning the
Computer Case on page 49.
When cleaning debris from under the keys, review all rules in
General Cleaning Safety Precautions
on page 48 before following these procedures:
CAUTION: Use safety glasses equipped with side shields before attempting to clean debris from
under the keys.
Visible debris underneath or between the keys may be removed by vacuuming or shaking.
Canned, pressurized air may be used to clean debris from under the keys. Caution should be used
as too much air pressure can dislodge lubricants applied under the wide keys.
If you remove a key, use a specially designed key puller to prevent damage to the keys. This tool
is available through many electronic supply outlets.
CAUTION: Never remove a wide leveled key (like the space bar) from the keyboard. If these
keys are improperly removed or installed, the keyboard may not function properly.
Cleaning under a key may be done with a swab moistened with isopropyl alcohol and squeezed
out. Be careful not to wipe away lubricants necessary for proper key functions. Use tweezers to
remove any fibers or dirt in confined areas. Allow the parts to air dry before reassembly.
Cleaning the Monitor
Wipe the monitor screen with a clean cloth moistened with water or with a towelette designed for
cleaning monitors. Do not use sprays or aerosols directly on the screen; the liquid may seep into
the housing and damage a component. Never use solvents or flammable liquids on the monitor.
To clean the monitor body follow the procedures in
Cleaning the Computer Case on page 49.
Routine Care
49

Table of Contents

Other manuals for HP Compaq Pro 6305

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq Pro 6305 and is the answer not in the manual?

HP Compaq Pro 6305 Specifications

General IconGeneral
Processor cache1 MB
Processor cores2
Processor modelA6-6400B
Processor familyAMD A6
Processor socketSocket FM2
Processor frequency3.9 GHz
Processor cache typeL2
Processor manufacturerAMD
Processor boost frequency4.1 GHz
Number of processors installed1
Memory slots4x DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory32 GB
Memory layout (slots x size)1 x 4 GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integrated-
Total storage capacity500 GB
On-board graphics cardYes
Discrete graphics card modelNot available
On-board graphics card modelAMD Radeon HD 8470D
On-board graphics card familyAMD Radeon HD 8000
Recovery operating systemWindows 8 Pro
Operating system installedWindows 7 Professional
Operating system architecture64-bit
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
HDMI ports quantity0
USB 2.0 ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Product typePC
Motherboard chipsetAMD A75
Power supply320 W
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth431 mm
Width177 mm
Height377 mm
Weight9300 g
