HP Compaq Pro 6305

Table 6-1 System Board Connections (continued)
No. System Board Connector System Board Label Color Component
16 USB MEDIA black USB Device, such as a Media Card
Reader
17 PCI Express x1 X1PCIEXP1 black Expansion Card
18 PCI Express x16 downshifted
to a x4
X4PCIEXP white Expansion Card
19 PCI Express x16 X16PCIEXP black Expansion Card
20 PCI PCI1 white Expansion Card
Drives
Description Spare part number
DVD±RW drive 660408-001
690418-001
DVD-ROM drive 682550-001
Blu-ray BD-Writer XL Drive 682219-001
1 TB hybrid hard drive (8-GB SSD) 724937-001
1 TB, 7200 rpm SATA hard drive 636930-001
500 GB hybrid hard drive (8-GB SSD) 724938-001
500 GB, 7200 rpm, 2.5 inch, SED, SATA hard drive 696422-001
500 GB, 7200 rpm SATA hard drive 636929-001
320 GB, 7200 rpm SATA hard drive, 2.5-inch 634824-001
250 GB, 7200 rpm SATA hard drive 636927-001
256 GB Solid State Drive (SSD), self-encrypting (SED) 680020-001
160 GB Solid State Drive (SSD) 646809-001
128 GB Solid State Drive (SSD) 665961-001
120 GB Solid State Drive (SSD) 661841-001
70 Chapter 6 Removal and Replacement Procedures Microtower (MT) Chassis
