Front Bezel
Description Spare part number
Front bezel 689377-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 54)
2. Remove the access panel (
Computer Access Panel on page 55)
3. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
Figure 6-2 Removing the Front Bezel
56 Chapter 6 Removal and Replacement Procedures Microtower (MT) Chassis
