Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(3c) Touchpad bracket Not available as a
spare part
(4) WLAN module
Intel Wireless Wi-Fi6e AX 211 Wi-Fi + Bluetooth® 5.2 (MU-MIMO) M53366-005
Intel Wireless Wi-Fi6 AX 211 2 × 2 Wi-Fi + Bluetooth® 5.2 (MU-MIMO) M74879-005
(5) Memory modules
16 GB, DDR4-3200 L67710-005
8 GB, DDR4-3200 L46598-005
4 GB, DDR4-3200 L83673-005
(6) Solid-state drive
1 T, M2 2280, PCIe-4 × 4, NVMe value N04491-001
512 GB, M2 2280, PCIe-4 × 4, NVMe value N04490-001
(7) Speaker N13560-001
(8) System board (includes integrated processor)
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Intel Core i5-1240P processor with 4 GB of unied memory architecture (UMA) graphics memory N13551-601
Intel Core i7-1260P processor with 4 GB of UMA graphics memory N13552-601
Intel Core i5-1235U processor and 4 GB of discrete graphics memory N13549-601
Intel Core i7-1255U processor and 4 GB of discrete graphics memory N13550-601
(9) Battery (4 cell, 55 Whr, 3.72Ah) M24563-005
(10a) Heat sink (for models with UMA graphics) N13567-001
(10b) Heat sink (for models with discrete graphics) N13568-001
(11) Fan assembly
Fan assembly (left) for use in models with discrete graphics N18726-001
Fan assembly (right) for use in models with discrete graphics N18727-001
Fan assembly (left) for use in models with UMA graphics N13561-001
Fan assembly (right) for use in models with UMA graphics N13562-001
(12) Bottom cover (for models with natural silver nish with rubber feet) N13558-001
20 Chapter 3Illustrated parts catalog
