To install the solid-state drive, reverse the removal procedures.
NOTE: Solid-state drives are designed with a notch to prevent incorrect insertion.
Speakers
To remove the speakers, use this procedure and illustration.
Table 5-6
Speaker description and part number
Description Spare part number
Speaker Kit N13560-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 33).
2. Remove the bottom cover (see Bottom cover on page 33).
3. Remove the battery (see Battery on page 34).
Remove the speakers:
1. Disconnect the speaker cables on each side of the computer (1).
2. Remove the 2 Phillips M2.0 × 2.0 screw (2) that secures the speakers to the computer.
Speakers
41
