2. Remove the bracket from the system board (2).
Reverse this procedure to install the USB Type-C bracket.
Display assembly
To remove and disassemble the display assembly, use these procedures and illustrations.
Full hinge-up displays are not available as spare parts. Spare parts for displays are available only at the
subcomponent level.
Before removing thedisplay panel, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 33).
2. Remove the bottom cover (see Bottom cover on page 33).
3. Remove the battery (see Battery on page 34).
4. Remove the display assembly panel (Display assembly panel on page 45).
IMPORTANT: After replacing the display panel assembly or the system board, it is necessary to run the
service tool to have the new ambient light sensor (ALS) data written to the system BIOS. Please search for
the related advisory for more information.
IMPORTANT: After replacing the display panel assembly, it is necessary to reload the calibration data. Refer
to Service Advisory c06640672 for details on reloading the HP Display Control Panel Color Calibration Data
Reload Process.
IMPORTANT: After replacing the display panel assembly, it is necessary to update the Touch Panel
Firmware. Navigate to Help and Support at http://www.hp.com. Select Support, and then select Software &
Drivers to download and install the Touch Panel Firmware.
Remove the display assembly:
1. If you need to remove the display panel assembly, display panel cable, or any of the internal display
components, follow these steps.
Display assembly
53
