9. Remove the display panel side bracket (select models only) by removing the four Phillips screws (1) and
releasing the side bracket (2).
NOTE: If your computer model does not have side brackets, skip to the next step.
10. If it is necessary to remove the display panel cable or access the webcam and microphone, follow these
steps. With the display bezel upside down, disconnect the cable from the webcam/microphone (1) and
from the routing channel built into the back cover.
Carefully release the cable from the channel guides, the guides in the display hinge, and remove the
display panel cable (2). Lift the cable (3) to remove it.
46 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
