Table 5-12 IR board cable description and part number
Description Spare part number
IR board cable N13565-001
Before removing theIR board cable, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 33).
2. Remove the bottom cover (see Bottom cover on page 33).
3. Remove the battery (see Battery on page 34).
Remove the IR board cable:
1. Open the IR board cable's two ZIF connectors (1), and then remove the IR board cable (2).
IR board cable 51
