HP dc5100 - Microtower PC Service & Reference Guide

Service Reference Guide, dc5100 376220-001 7–15
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
7.6.1 Cable Connections
Cable To Cable Designator
Power Supply System board P1
Power Supply 1st SATA Hard drive P4
Power Supply System board (12V) P3
Power Supply Optical drive P6
Power Supply Diskette drive P2
Power Supply 2nd SATA Hard drive P5
Cable To PCA Designator
Diskette drive System board P10 (Floppy)
1st SATA Hard drive System board P60 (SATA 0)
ODD Data System board P20 (Secondary)
Heatsink fan System board P8 (CPU fan)
Front LED/power button System board P5 (F_PNL)
Front I/O USB System board P24 (Front USB)
Serial port connector System board P54 (Serial A)
Front I/O Audio System board P23 (Black)
System fan System board P9 (CH FAN)
Speaker System board P6 (Speaker)

HP dc5100 - Microtower PC Specifications

General

Processor	Intel Pentium 4 or Intel Celeron D
Memory	Up to 4 GB DDR2 SDRAM
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Operating System	Windows XP Professional
Optical Drive	DVD-ROM, CD-RW, or DVD+/-RW
Graphics	Intel Graphics Media Accelerator 900
Audio	Integrated audio
Expansion Slots	1 PCI Express x16, 3 PCI
Ports	1 Serial, 1 Parallel
Weight	Approx. 22 lbs (10 kg)
Processor Speed	Up to 3.8 GHz
Storage	40 GB to 250 GB HDD
