HP dc5100 - Microtower PC Service & Reference Guide

Service Reference Guide, dc5100 376220-001 A–5
Connector Pin Assignments
Ultra SCSI
Connector and Icon
Pin Signal Pin Signal Pin Signal Pin Signal
1-11
12
13
14
Ground
Reserved
Open
Reserved
29
30
31
32
DB3
DB4
DB5
DB6
37
38
39
40
Reserved
TERMPWR
Reserved
Ground
45
46
47
48
RST #
MSG #
SEL #
C/D
15-25
26
27
28
Ground
DB0
DB1
DB2
33
34
35
36
DB7
DBP
Ground
Ground
41
42
43
44
ATN #
Ground
BSY #
ACK #
49
50
REQ #
Input/Output
External Infrared Transceiver
Connector and Icon
Pin Signal Pin Signal Pin Signal
1
2
3
Transmit
Receive
Ground
4
5
6
5V
Mode
Not Used
7
8
Not Used
Not Used
Monitor
Connector and Icon
Pin Signal Pin Signal Pin Signal
1
2
3
Red Analog
Green Analog
Blue Analog
6
7
8
Ground
Ground
Ground
11
12
13
Not used
DDC Serial Data
Horizontal Sync
4
5
Not used
Ground
9
10
+5V (fused)
Ground
14
15
Vertical Sync
DDC Serial Clock

HP dc5100 - Microtower PC Specifications

General

Processor	Intel Pentium 4 or Intel Celeron D
Memory	Up to 4 GB DDR2 SDRAM
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Operating System	Windows XP Professional
Optical Drive	DVD-ROM, CD-RW, or DVD+/-RW
Graphics	Intel Graphics Media Accelerator 900
Audio	Integrated audio
Expansion Slots	1 PCI Express x16, 3 PCI
Ports	1 Serial, 1 Parallel
Weight	Approx. 22 lbs (10 kg)
Processor Speed	Up to 3.8 GHz
Storage	40 GB to 250 GB HDD
