Service Reference Guide, dx2200 MT 415606-001 6–11
Removal and Replacement Procedures— Microtower (MT) Chassis
6.7.1 Cable Connections
Cable To Cable Designator
Power Supply 1st SATA Hard drive P6
Power Supply System board, 24-pin P1
Power Supply CPU power, 4-pin P2
Power Supply 1st Optical drive P3
Power Supply 2nd Optical drive P4
Power Supply 2nd SATA Hard drive P5
Power Supply DIskette drive P7
Cable To PCA Designator
Diskette drive System board FDD1 (Black)
1st SATA Hard drive System board SATA 0 (Orange)
2nd SATA Hard drive System board SATA 1 (Orange)
ODD Data System board IDE1(Blue)
ODD Audio System board JCD1 (Black)
Heatsink fan System board CPU FAN 2 (Brown)
Secondary system fan System board SYSFAN1(White)
Front power on button System board JFPF1 (Black)
Front I/O USB System board JUSB1 (Black)
Speaker System board AUDIO1 (White)
Front audio System board AUD1 (Black)

HP dx2200 - Microtower PC Specifications

General

Chipset	Intel 945G Express
Memory	Up to 4 GB DDR2 SDRAM
Graphics	Integrated Intel Graphics Media Accelerator 950
Audio	Integrated High Definition audio
Network	Integrated 10/100/1000 Ethernet
Front Ports	2 USB 2.0, headphone, microphone
Power Supply	300W
Processor	Intel Pentium 4 or Intel Celeron
Optical Drive	DVD-ROM
Expansion Slots	1 PCI Express x16, 3 PCI
Operating System	Windows XP Professional or FreeDOS
Rear Ports	4 USB 2.0, VGA, Ethernet, Line-in, Line-out, Microphone
Storage	SATA Hard Drive (capacity varies)
USB Ports	8 USB 2.0 (2 front, 4 rear, 2 internal)
