6–12 415606-001 Service Reference Guide, dx2200 MT

Removal and Replacement Procedures— Microtower (MT) Chassis

6.8 Drives

The computer supports up to four drives that may be installed in various configurations.

This Section describes the procedure for replacing or upgrading the storage drives. A Torx T-15

screwdriver is needed to remove and install the guide screws on a drive.

CAUTION: Make sure personal files on the hard drive are backed up to an external storage device

before removing the hard drive. Failure to do so will result in data loss. After replacing the primary hard

drive, you will need to run the Restore Plus! CD to load the Compaq factory-installed files.

6.8.1 Drive Positions

Drive Positions

Item Description Item Description

1 Optical* drive 4 Internal hard drive (secondary)

2 Optical* drive 5 Internal hard drive (primary)

3 External

3.5”

*An optical drive is a CD-ROM, CD-R/RW, DVD-ROM, DVD-R/RW, or CD-RW/DVD Combo

drive.

Optional media card reader illustrated.
