HP dx2200 - Microtower PC User Manual

Service Reference Guide, dx2200 MT 415606-001 D–1
D
Memory
Computers equipped with Intel-based processors come with double data rate synchronous
dynamic random access memory (DDR2-SDRAM) dual inline memory modules (DIMMs).
The memory sockets on the system board can be populated with up to two industry-standard
DIMMs. These memory module slots are populated with at least one pre installed memory
module. To achieve the maximum memory support, you can populate the system board with up
to 2GB of memory configured in a high-performing dual channel mode.
For proper system operation, the computer supports DDR2-SDRAM DIMMs. The DIMMs must
be industry-standard 240-pin, unbuffered PC2 5300 667 MHz- compliant, 1.9 volt DDR2-
SDRAM DIMMs. The DDR2-SDRAM DIMMs must also:
■ support CAS latency 4 (CL = 4) for PC2 5300 667 MHz
■ contain the mandatory JEDEC SPD information
In addition, the computer supports:
■ 256Mbit, 512Mbit, and 1 Gbit non-ECC memory technologies
■ single-sided and double-sided DIMMS
■ DIMMs constructed with x8 and x16 DDR devices; DIMMs constructed with x4 SDRAM
are not supported
■ The maximum operational speed is determined by the slowest DIMM in the system.
✎
The system will not start if you install unsupported DIMMs.

HP dx2200 - Microtower PC Specifications

General

Chipset	Intel 945G Express
Memory	Up to 4 GB DDR2 SDRAM
Graphics	Integrated Intel Graphics Media Accelerator 950
Audio	Integrated High Definition audio
Network	Integrated 10/100/1000 Ethernet
Front Ports	2 USB 2.0, headphone, microphone
Power Supply	300W
Processor	Intel Pentium 4 or Intel Celeron
Optical Drive	DVD-ROM
Expansion Slots	1 PCI Express x16, 3 PCI
Operating System	Windows XP Professional or FreeDOS
Rear Ports	4 USB 2.0, VGA, Ethernet, Line-in, Line-out, Microphone
Storage	SATA Hard Drive (capacity varies)
USB Ports	8 USB 2.0 (2 front, 4 rear, 2 internal)
