4. Connect one end of the power cord to the AC adapter and the other end to a grounded AC outlet. Then

connect the AC adapter to the power connector on the monitor.

WARNING! To reduce the risk of electric shock or damage to the equipment:

Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

Plug the power cord into a grounded (earthed) AC outlet that is easily accessible at all times.

Disconnect power from the equipment by unplugging the power cord from the AC outlet.

For your safety, do not place anything on power cords or cables. Arrange them so that no one can

accidentally step on or trip over them. Do not pull on a cord or cable. When unplugging the power cord

from the AC outlet, grasp the cord by the plug.

Connecting USB devices

USB ports are used to connect devices such as a digital camera, USB keyboard, or USB mouse. There are four

USB ports on the monitor to connect to a device (downstream): two USB Type-A on the rear and two USB

Type-A on the side. There is one USB Type-C port on the rear to act as a hub (upstream).

NOTE: You must connect the USB Type-C cable from the source device (computer) to the rear of the monitor

to enable the USB Type-A ports to serve as a USB hub for a mouse, keyboards, phones, external hard drives,

and practically anything that is USB-connected and can accept 5 V.

12 Chapter 1 Getting started

Other manuals for HP E14 G4

Need help?

Do you have a question about the HP E14 G4 and is the answer not in the manual?

General

Color gamut	72 %
Pixel pitch	0.161 x 0.161 mm
Screen shape	Flat
Pixel density	157 ppi
Display diagonal	14 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	59 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 80 kHz
Contrast ratio (typical)	800:1
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Built-in USB hub	Yes
DisplayPorts quantity	0
USB upstream port type	USB Type-C
Power consumption (standby)	0.3 W
Power consumption (typical)	6 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	61 mm
Package width	405 mm
Package height	284 mm
Package weight	1540 g
Tilt angle range	0 - 78 °
Certification	BIS; BSMI; CB; CCC; CE; cTUVus; EAC; ENERGY STAR®; FCC; ICES; ISE for Cambodia; ISO 9241-307; KC/KCC; NOM; SEPA; Taiwan Green Mark; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; WW application; UAE
Product color	White
Market positioning	Business
