HP E22 G4 Product End-Of-Life Disassembly Instructions

EL-MF877-00 Page 2
Template Revision C
Last revalidation date 09-May-2018
HPI instructions for this template are available at EL-MF877-01
Item Description Notes
Quantity
of items
included
in
product
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and
toner
Include the cartridges, print heads, tubes, vent chambers, and
service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components and
materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screw driver of "+" type
Hexagonal nut screw driver for D-SUB connector
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment
including the required steps to remove the external enclosure:
1. Remove the hinge assy by press the hook on the rear cover.
2. Remove the rear cover screws by the screwdriver.
3. Remove the rear cover from the top side by hand
4. Disconnect connectors
5. Tear out all taps and disconnect the connectors by hands
6. Remove the screws by the screwdriver
7. Remove the hex screws by the hex screwdriver
8. Remove the screws by the screwdrive

HP E22 G4 Specifications

General

Color gamut	72 %
Pixel pitch	0.247 x 0.247 mm
Screen shape	Flat
Pixel density	94 ppi
Display diagonal	21.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Viewable size, vertical	267.7 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	476 mm
Digital vertical frequency	50 - 60 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Number of USB Type-B upstream ports quantity	1
Sustainability certificates	ENERGY STAR
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Package depth	350 mm
Package width	565 mm
Package height	211 mm
Package weight	7700 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	23 W
Product color	Black, Silver
Market positioning	Business
Cables included	AC, DisplayPort, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	200.7 mm
Width (with stand)	488.7 mm
Height (with stand)	480.6 mm
Weight (with stand)	5300 g
Depth (without stand)	47 mm
Height (without stand)	294.6 mm
Weight (without stand)	2880 g
