21
or move the mouse to exit
Sleep mode.
Video card is incompatible.
Open the OSD menu and
select the Input Control menu.
Set Auto-Switch Input to Off
and manually select the input
Image appears
blurred, indistinct,
or too dark.
Brightness is too low.
Open the OSD menu and
select Brightness to adjust the
brightness scale as needed.
Check Video Cable
is displayed on
screen.
Monitor video cable is disconnected.
Connect the appropriate video
signal cable between the
computer and monitor. Be
sure that the computer power
is off while you connect the
video cable.
Input Signal Out
of Range is
displayed on
screen.
Video resolution and/or refresh rate are set higher
than what the monitor supports.
Change the settings to a
supported setting.
The monitor is off,
but it did not seem
to enter into Sleep
mode.
The monitor’s power saving control is disabled.
Open the OSD menu and
select Power Control > Auto-
Sleep Mode and set auto-sleep
to On.
On-Screen Menus
are Locked is
displayed.
The monitor’s OSD lock function is enabled.
Press and hold the Menu
button on the front bezel to
10 seconds to disable the
OSD lockout function.
Power Button is
Locked is
Displayed
The monitor’s power button is locked.
Press and hold the power
button for 10 seconds to
disable the power button lock
function.

Other manuals for HP E22 G4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP E22 G4 and is the answer not in the manual?

HP E22 G4 Specifications

General IconGeneral
Color gamut72 %
Pixel pitch0.247 x 0.247 mm
Screen shapeFlat
Pixel density94 ppi
Display diagonal21.5 \
Surface hardness3H
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Maximum refresh rate60 Hz
Viewable size, vertical267.7 mm
Contrast ratio (dynamic)5000000:1
Contrast ratio (typical)1000:1
Display number of colors-
Viewable size, horizontal476 mm
Digital vertical frequency50 - 60 Hz
Digital horizontal frequency30 - 80 kHz
Display brightness (typical)250 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version1.4
DisplayPort version1.2
USB upstream port typeUSB Type-B
USB Type-A downstream ports quantity4
Number of USB Type-B upstream ports quantity1
Sustainability certificatesENERGY STAR
Pivot angle-90 - 90 °
Tilt angle range-5 - 23 °
Panel mounting interface100 x 100 mm
Package depth350 mm
Package width565 mm
Package height211 mm
Package weight7700 g
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
AC input voltage100 - 240 V
Energy efficiency scaleA to G
Power consumption (max)50 W
Power consumption (standby)0.5 W
Power consumption (typical)23 W
Product colorBlack, Silver
Market positioningBusiness
Cables includedAC, DisplayPort, HDMI, USB
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)200.7 mm
Width (with stand)488.7 mm
Height (with stand)480.6 mm
Weight (with stand)5300 g
Depth (without stand)47 mm
Height (without stand)294.6 mm
Weight (without stand)2880 g
