17
Connector repair
This procedure includes HDMI, DisplayPort, USB 3.0A connectors.
The connectors are on the main board (board part number CBPR2A6HPQ1)
The connectors’ identifiers are as follows:
Connector
Location
HDMI
CN502
DP
CN501
USB3.0A( UP)
CN105
USB 3.0A(1/2)
CN106/ CN104
