9
USB-C
USB1
Molex
https://www.digikey.com
PN:
900-2171840001DKR-ND
Cut off the Pin as below
USB-A
USB2
Molex
https://www.digikey.com
PN:
1002-004-01010
Cut off the Pin as below
NOTE: The connector may need to be modified to meet functionality, regulatory and safety requirements if
it is not an exact match.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for your computer, go to http://partsurfer.com, select your country or region, and then
follow the on-screen instructions.
Internal and External Power Supplies are available for purchase from the following EU distributor: EET
https://www.eetgroup.com/en-eu/

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP E24u G4 and is the answer not in the manual?

HP E24u G4 Specifications

General IconGeneral
Color gamut72 %
Pixel pitch0.274 x 0.274 mm
Screen shapeFlat
Backlight typeEdge LED
Display diagonal23.8 \
Surface hardness3H
Display technologyLCD
Native aspect ratio16:9
Vertical scan range50 - 60 Hz
Maximum refresh rate60 Hz
Horizontal scan range30 - 80 kHz
Contrast ratio (dynamic)5000000:1
Display number of colors-
Display brightness (typical)250 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMIYes
HDMI version1.4
DisplayPort version1.2
USB upstream port typeUSB Type-C
USB Type-A downstream ports quantity4
AC input voltage100 - 240 V
Power consumption (max)131 W
Power consumption (standby)0.5 W
Power consumption (typical)22 W
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)20 - 80 %
Package depth223 mm
Package width611 mm
Package height392 mm
Package weight8890 g
Pivot angle-90 - 90 °
Tilt angle range-5 - 23 °
Height adjustment150 mm
Panel mounting interface100 x 100 mm
Cables includedAC, USB Type-C
Product colorBlack, Silver
Market positioningBusiness
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)207 mm
Width (with stand)539.4 mm
Height (with stand)494.9 mm
Weight (with stand)6300 g
Depth (without stand)47 mm
Height (without stand)323.3 mm
