HP E27m G4 User Manual

26
computer’s on-board video
sources.
Image appears
blurred,
indistinct, or too
dark.
Brightness is too low. Open the OSD menu and
select Brightness
to adjust
the brightness scale as
needed.
Check Video
Cable is
displayed on
screen.
Monitor video cable is disconnected.
Connect the appropriate
video signal cable
between the computer and
monitor. Be sure that the
computer power is off
while you connect the
video cable.
Input Signal Out
of Range is
displayed on
screen.
Video resolution and/or refresh rate are set
higher than what the monitor supports.
Change the settings to a
supported setting.
The monitor
does not enter
into a low-
power
sleep state.
The monitor's power saving control is disabled. Open the OSD menu and
select Power, select Auto-
Sleep Mode, and then set
auto-sleep to On.
“OSD Lockout”
is displayed
The monitor’s OSD lock function is enabled. Press and hold the Menu
button for 10 seconds to
disable the OSD Lockout
function.
Power Button is
Locked is
Displayed
The monitor's Power Button Lockout function is
enabled.
Press and hold the Power
button for 10 seconds to
unlock the power button
function.

HP E27m G4 Specifications

General

Color gamut	99 %
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440
Product color	Black, Silver
Market positioning	Business
Megapixel	5 MP
RMS rated power	10 W
Number of speakers	2
Pivot angle	-90 - 90 °
Cable lock slot	-
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	160 W
Power consumption (standby)	0.5 W
Power consumption (typical)	51 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
HDMI version	1.4
DisplayPort version	1.2
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	4
Cables included	AC, USB Type-C to USB Type-C
Package depth	190 mm
Package width	695 mm
Package height	483 mm
Package weight	11970 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	216 mm
Height (with stand)	551 mm
Weight (with stand)	8520 g
Depth (without stand)	47 mm
Width (without stand)	612.8 mm
Height (without stand)	396.6 mm
