HDMI connector – J401

Repair the HDMI connector:

1) Use a soldering iron and a de-soldering pump to remove as much solder as possible

from the pin.

2) Use a hot air gun to melt the solder on the pins.

3) Lift the J3 connector from the circuit board.

4) Place the new component on the circuit board. Be sure that it matches the footprint.

5) Solder the new component.

Questions and Answers:

Need help?

Do you have a question about the HP E32k G5 and is the answer not in the manual?

General

Display Size	31.5 inches
Panel Type	IPS
Refresh Rate	60 Hz
Aspect Ratio	16:9
Contrast Ratio	1000:1
Color Gamut	99% sRGB
Tilt	-5° to +20°
Pivot	Yes
VESA Mount	100 x 100 mm
Speakers	No
Response Time	5 ms
Viewing Angle	178° horizontal / 178° vertical
Connectivity	HDMI, DisplayPort, USB-C, USB Hub
Resolution	3840 x 2160 (4K UHD)
Swivel	±45°
