Menu Reference
Front Panel Menu Reference "Rel/Offset" Menu
HP E4418B User’s Guide 3-19
The softkey menu structured to this hardkey affects the currently selected
window.
Press this hardkey to access the “Rel/Offset” menu which allows you to;
compare any measurement result in dB or percentage (%) to a reference
value and set display offsets.
•
Press this softkey to toggle the reference value on or off. The
default is “Off”. The reference value is set using .
•
Press this softkey to use the current reading as the reference
value. This allows you to compare any measurement result in dB
or percentage (%). is automatically set to “On” when
is pressed.
•
Press this softkey to toggle the display offset value on or off. The
default is “Off”. The offset value is set using .
•
Press this softkey to enter a display offset value. Use the ,
, and hardkeys to change the value. To confirm
your choice press . is automatically set to
“On” when a value is entered using .
Rel
Offset
Rel Off On
Rel
Rel
Rel Off On
Rel
Offset Off On
Offset
Offset
dB Offset Off On
Offset
