12
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
EC 470uF 20% 25V
10x12 5000 hr 1.6A ENB1
C9103/C9102/
C9906/C9919/C9918
TEAPO
(Element14)
KSY477M025S1A5H12K
Connectors by manufacturer
Component
description
Location identifier
Component
distributor
Distributer part number
HDMI
CN502
RS PRO(RS)
RS Stock No.:
724-8959
DP
CN501
Molex(RS)
47272-0001
(Molex)
USB3.0 A
CN1003/CN1004
RS
10117836-002LF
(Amphenol ICC)
USB 3.0 A
CN1032/CN1033
RS
SD-48394-001
MOLEX
USB type C
CN1008/CN504
RS
632722110112
WE)
RJ45
CN1006
tme
5557484-1
TE CONNECTIVITY
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need
modifications to meet functional, safety and regulatory requirements accordingly if it doesn’t match
exactly.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
Internal and External Power Supplies are available for purchase from the following EU distributor: EET
https://www.eetgroup.com/en-eu/
NOTE: HP continually improves and changes product parts. For complete and current information
about supported parts for your product, go to https://partsurfer.hp.com/Search.aspx, select your
country or region, and then follow the on-screen instructions.
