Setting up a WLAN
To set up a WLAN and connect to the Internet, you need the following equipment:
A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from
an Internet service provider
A wireless router (2) (purchased separately)
A wireless computer (3)
NOTE: Some modems have a built-in wireless router. Check with your ISP to determine what type
of modem you have.
The illustration below shows an example of a wireless network installation that is connected to the
Internet.
As your network grows, additional wireless and wired computers can be connected to the network to
access the Internet.
For help in setting up your WLAN, see the information provided by your router manufacturer or your
ISP.
Configuring a wireless router
For help in configuring a wireless router, see the information provided by your router manufacturer or
your ISP.
NOTE: It is recommended that you initially connect your new wireless computer to the router by
using the network cable provided with the router. When the computer successfully connects to the
Internet, disconnect the cable, and access the Internet through your wireless network.
Protecting your WLAN
When you set up a WLAN or access an existing WLAN, always enable security features to protect
your network from unauthorized access. WLANs in public areas (hotspots) like coffee shops and
airports may not provide any security. If you are concerned about the security of your computer in a
hotspot, limit your network activities to e-mail that is not confidential and basic Internet surfing.
Wireless radio signals travel outside the network, so other WLAN devices can pick up unprotected
signals. Take the following precautions to protect your WLAN:
Use a firewall.
A firewall checks both data and requests for data that are sent to your network, and discards any
suspicious items. Firewalls are available in both software and hardware. Some networks use a
combination of both types.
Use wireless encryption.
Wireless encryption uses security settings to encrypt and decrypt data that is transmitted over
the network. For more information, access HP Support Assistant. To access HP Support
Assistant, from the Start screen, select the HP Support Assistant app.
Connecting to a wireless network 21

Table of Contents

Other manuals for HP Elite x2 1011 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Elite x2 1011 G1 and is the answer not in the manual?

HP Elite x2 1011 G1 Specifications

General IconGeneral
SteppingF0
Tjunction95 °C
Processor codeSR23L
Processor cache4 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel® Core™ M
Processor seriesIntel Core M-5Y Mobile series
Processor threads4
Processor codenameBroadwell
Processor frequency1.1 GHz
Processor cache typeL3
Processor manufacturerIntel
Processor package size30 x 16.5 mm
Conflict-Free processorYes
Processor front side bus- MHz
Processor boost frequency2.6 GHz
Processor operating modes32-bit, 64-bit
Graphics & IMC lithography14 nm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)4.5 W
Scenario Design Power (SDP)3.5 W
Configurable TDP-down frequency0.6 GHz
Internal memory8 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Storage mediaSSD
Compatible memory cardsMicroSD (TransFlash)
Internal storage capacity256 GB
Display diagonal11.6 \
Touch technologyMulti-touch
Graphics cardHD Graphics 5300
Rear camera typeSingle camera
Rear camera resolution (numeric)5 MP
Front camera resolution (numeric)2 MP
Processor ARK ID84669
Processor socketBGA 1234
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Near Field Communication (NFC)-
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of originChina
Device typeTablet PC
Form factorSlate
Product colorBlack, Silver
Intel Identity Protection Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Battery capacity- mAh
Battery life (max)9 h
PlatformWindows
Operating system installedWindows 8.1 Pro
Weight and Dimensions IconWeight and Dimensions
Depth192.7 mm
Width298 mm
Height10.7 mm
Weight780 g
