NOTE: If you connect your computer to a network, consult the network administrator before
installing any software updates, especially system BIOS updates.
BIOS installation procedures vary. Follow any instructions that are revealed on the screen after the
download is complete. If no instructions are revealed, follow these steps:
1. From the Start screen, type file, and then select File Explorer.
2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:).
3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains
the update.
4. Double-click the file that has an .exe extension (for example,
filename
.exe).
The BIOS installation begins.
5. Complete the installation by following the on-screen instructions.
NOTE: After a message on the screen reports a successful installation, you can delete the
downloaded file from your hard drive.
Synchronizing the tablet and keyboard
When you attach the tablet to the keyboard and restart the computer, the BIOS checks to see if the
Embedded Controller firmware on the keyboard needs to be synchronized, and will start the
synchronization. If the synchronization is interrupted, a notification screen displays for 10 seconds
before the tablet restarts and attempts to synchronize again.
NOTE: The Embedded Controller firmware will only synchronize if the tablet or keyboard battery is
more than 50% charged, or if your tablet is connected to AC power.
Using MultiBoot
About the boot device order
As the computer starts, the system attempts to boot from enabled devices. The MultiBoot utility,
which is enabled at the factory, controls the order in which the system selects a boot device. Boot
devices can include optical drives, diskette drives, a network interface card (NIC), hard drives, and
USB devices. Boot devices contain bootable media or files that the computer needs to start and
operate properly.
NOTE: Some boot devices must be enabled in Computer Setup before they can be included in the
boot order.
You can change the order in which the computer searches for a boot device by changing the boot
order in Computer Setup. You can also press esc or the volume down button while the “Hold the
Volume Down button to enter the BIOS Startup Menu” message is displayed at the bottom of the
screen, and then press or tap f9. Selecting f9 displays a menu that shows the current boot devices
and allows you to select a boot device. Or, you can use MultiBoot Express to set the computer to
prompt you for a boot location each time the computer turns on or restarts.
78 Chapter 11 Computer Setup (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI)

Table of Contents

Other manuals for HP Elite x2 1011 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Elite x2 1011 G1 and is the answer not in the manual?

HP Elite x2 1011 G1 Specifications

General IconGeneral
SteppingF0
Tjunction95 °C
Processor codeSR23L
Processor cache4 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel® Core™ M
Processor seriesIntel Core M-5Y Mobile series
Processor threads4
Processor codenameBroadwell
Processor frequency1.1 GHz
Processor cache typeL3
Processor manufacturerIntel
Processor package size30 x 16.5 mm
Conflict-Free processorYes
Processor front side bus- MHz
Processor boost frequency2.6 GHz
Processor operating modes32-bit, 64-bit
Graphics & IMC lithography14 nm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)4.5 W
Scenario Design Power (SDP)3.5 W
Configurable TDP-down frequency0.6 GHz
Internal memory8 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Storage mediaSSD
Compatible memory cardsMicroSD (TransFlash)
Internal storage capacity256 GB
Display diagonal11.6 \
Touch technologyMulti-touch
Graphics cardHD Graphics 5300
Rear camera typeSingle camera
Rear camera resolution (numeric)5 MP
Front camera resolution (numeric)2 MP
Processor ARK ID84669
Processor socketBGA 1234
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Near Field Communication (NFC)-
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of originChina
Device typeTablet PC
Form factorSlate
Product colorBlack, Silver
Intel Identity Protection Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Battery capacity- mAh
Battery life (max)9 h
PlatformWindows
Operating system installedWindows 8.1 Pro
Weight and Dimensions IconWeight and Dimensions
Depth192.7 mm
Width298 mm
Height10.7 mm
Weight780 g
