6 Power management
NOTE: A computer may have a power button or a power switch. The term
power button
is used
throughout this guide to mean both types of power controls.
Shutting down (turning off) the computer
CAUTION: Unsaved information is lost when the computer shuts down.
The shutdown command closes all open programs, including the operating system, and then turns off
the display and computer.
Shut down the computer under any of the following conditions:
When you need to replace the battery or access components inside the computer
When you are connecting an external hardware device that does not connect to a Universal
Serial Bus (USB) port
When the computer will be unused and disconnected from external power for an extended
period
Although you can turn off the computer with the power button, the recommended procedure is to use
the Windows shutdown command:
NOTE: If the computer is in the Sleep state or in Hibernation, you must first exit Sleep or
Hibernation before shutdown is possible by briefly pressing the power button.
1. Save your work and close all open programs.
2. From the Start screen, point to the upper-right or lower-right corner of the screen.
3. Click Settings, click the Power icon, and then click Shut down.
– or –
Right-click the Start button in the lower-left corner of the screen, select Shut down or signout,
and then select Shut down.
If the computer is unresponsive and you are unable to use the preceding shutdown procedure, try the
following emergency procedures in the sequence provided:
Press ctrl+alt+delete. Click the Power icon, and then click Shut Down.
Press and hold the power button for at least 5 seconds.
Disconnect the computer from external power.
On models with a user-replaceable battery, remove the battery. On models with a factory-sealed
battery, press and hold the power button at least 15 seconds.
Shutting down (turning off) the computer 45

Table of Contents

Other manuals for HP Elite x2 1011 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Elite x2 1011 G1 and is the answer not in the manual?

HP Elite x2 1011 G1 Specifications

General IconGeneral
SteppingF0
Tjunction95 °C
Processor codeSR23L
Processor cache4 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel® Core™ M
Processor seriesIntel Core M-5Y Mobile series
Processor threads4
Processor codenameBroadwell
Processor frequency1.1 GHz
Processor cache typeL3
Processor manufacturerIntel
Processor package size30 x 16.5 mm
Conflict-Free processorYes
Processor front side bus- MHz
Processor boost frequency2.6 GHz
Processor operating modes32-bit, 64-bit
Graphics & IMC lithography14 nm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)4.5 W
Scenario Design Power (SDP)3.5 W
Configurable TDP-down frequency0.6 GHz
Internal memory8 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Storage mediaSSD
Compatible memory cardsMicroSD (TransFlash)
Internal storage capacity256 GB
Display diagonal11.6 \
Touch technologyMulti-touch
Graphics cardHD Graphics 5300
Rear camera typeSingle camera
Rear camera resolution (numeric)5 MP
Front camera resolution (numeric)2 MP
Processor ARK ID84669
Processor socketBGA 1234
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Near Field Communication (NFC)-
Microphone inNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of originChina
Device typeTablet PC
Form factorSlate
Product colorBlack, Silver
Intel Identity Protection Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Battery capacity- mAh
Battery life (max)9 h
PlatformWindows
Operating system installedWindows 8.1 Pro
Weight and Dimensions IconWeight and Dimensions
Depth192.7 mm
Width298 mm
Height10.7 mm
Weight780 g
