Nano SIM card
CAUTION: To prevent damage to the connectors, use minimal force when inserting a nano SIM card.
CAUTION: To prevent damage to a SIM card or a computer, do not change the size of a SIM card by cutting or
sanding the card.
NOTE: SIM blank does not have hole and should be removed when the system board is removed.
1. Position the computer display-side up on a at surface.
2. Insert the removal tool or a small straightened paper clip into the card tray access hole until the card
tray is ejected
(1).
3. Remove the tray (2) from the computer and remove the card (3).
4. Replace the tray in the computer, and then press in gently on the tray (4) until it is rmly seated.
To install a SIM card, reverse the steps.
32 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
