Display panel
Display panel Spare part number
Back cover for use in models without WWAN L31357-001
Back cover for use in models with WWAN L31358-001
Display panel, WUXGA+, privacy (includes privacy panel, touch board, IR bezel, LCD cable, and touch
control cable)
L31364-001
Display panel, 3k2k, models without an IR camera (includes panel, touch board, bezel, LCD cable,
and touch control cable)
L31365-001
Display panel, 3k2k, models with an IR camera (includes panel, touch board, IR bezel, LCD cable,
and touch control cable)
L31886-001
IMPORTANT: Make special note of each screw size and location during removal and replacement.
Before removing the display panel, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
Remove the display panel:
1. Lift the kickstand (1), and then remove the four Torx T5 1.6×2.5 screws (2) securing the back cover.
Component replacement procedures 33
