HP Elite x2 1013 G3 User Manual

IR camera
Description Spare part number
IR camera L31350-001
IR camera bezel L31374-001 (Plastics Kit)
Before removing the IR camera, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Display panel (see Display panel on page 33)
b. Disconnect the battery cable (see Battery on page 36)
c. Remove the camera connector bracket (see Camera connector bracket on page 44)
Remove the camera:
CAUTION: Use care to prevent damaging the zero-insertion force (ZIF) connector and ribbon cable.
▲ Disconnect the camera cable from the reverse ZIF connector (1), and then use a tool to pry the camera
module up to disengage the adhesive that secures it to the computer (2).
Reverse this procedure to replace the IR camera.
Component replacement procedures 45

HP Elite x2 1013 G3 Specifications

General

Display Size	13 inches
Resolution	3000 x 2000
Operating System	Windows 10 Pro
Battery Life	Up to 10 hours
Graphics	Intel UHD Graphics 620
Front Camera	5 MP
Rear Camera	8 MP
Camera	Front: 5 MP, Rear: 8 MP
Processor	Intel Core i5 or i7
RAM	8GB or 16GB
Storage	256 GB / 512 GB / 1 TB SSD
Ports	2 x USB-C, 1 x headphone/microphone combo
Wireless	Bluetooth 4.2
Security	Fingerprint reader, IR camera
