HP Elite x2 1013 G3 User Manual

Microphone board
Description Spare part number
Microphone board (includes ambient light sensor) L31344-001
Before removing the microphone board, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Display panel (see Display panel on page 33)
b. Disconnect the battery cable (see Battery on page 36)
c. IR camera (see IR camera on page 45)
d. HD camera (see Front-facing HD camera on page 46)
e. Rear-facing camera (see Rear-facing camera on page 47)
Remove the microphone board:
CAUTION: Use care to prevent damaging the zero-insertion force (ZIF) connector and ribbon cable.
1. Disconnect the microphone cable from the system board (1), and then lift the microphone board to
remove it (2).
48 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP Elite x2 1013 G3 Specifications

General

Display Size	13 inches
Resolution	3000 x 2000
Operating System	Windows 10 Pro
Battery Life	Up to 10 hours
Graphics	Intel UHD Graphics 620
Front Camera	5 MP
Rear Camera	8 MP
Camera	Front: 5 MP, Rear: 8 MP
Processor	Intel Core i5 or i7
RAM	8GB or 16GB
Storage	256 GB / 512 GB / 1 TB SSD
Ports	2 x USB-C, 1 x headphone/microphone combo
Wireless	Bluetooth 4.2
Security	Fingerprint reader, IR camera
