Table 3-2 Display component descriptions and part numbers (continued)
Item Component Spare part number
IR camera N05870-001
Microphone module N05863-001
(3) Display panel (includes cover and bezel adhesive)
NOTE: Display panel tape is available as spare part number N00351-001.
FHD, 400 nits N00086-001
FHD, 250 nits N00084-001
FHD, 250 nits, touch screen N00085-001
HD, 250 nits N00087-001
(4) Hinges (left and right; includes bezel trim pieces, bezel trim protective shielding, display panel
adhesive, and bezel adhesive)
M21732-001
(5) Display/camera cable (includes cover and bezel adhesive) N03217-001
(6) WLAN antennas and cables (includes camera, cover, and bezel adhesive) N03219-001
(7) WWAN antennas and cables (includes cover and bezel adhesive)
400 nit displays N03220-001
250 nit displays N03221-001
(8) Display back cover (includes bezel adhesive)
Models with a 400 nit panel, without WWAN N03209-001
Models with 400 nit panel, with WWAN N03210-001
Models with a 250 nit panel, without WWAN N03211-001
Models with 250 nit panel, with WWAN N03212-001
Cable Kit
To identify the contents of the Cable Kit, use this table.
Table 3-3
Cable Kit content descriptions and part number
Component Spare part number
Cable Kit, includes: N03218-001
I/O board cable
I/O board cable (USB 3.0)
Touchpad cable
Fingerprint reader board cable
NFC board cable
Smart card reader board cable
Cable Kit 25
