are available as spare part number N03220-001 for models with 400 nit displays and N03221-001 for
models with 250 nit displays.
Display rear covers are available as the following spare part numbers:
N03209-001: Models with a 400 nit panel, without WWAN
N03210-001: Models with a 400 nit panel, with WWAN
N03211-001: Models with a 250 nit panel, without WWAN
N03212-001: Models with a 250 nit panel, with WWAN
Reverse this procedure to reassemble and replace the display assembly.
Top cover with keyboard (includes smart card board)
The top cover with keyboard remains after removing all other spare parts from the computer. In this section,
the rst table provides the main spare part number for the top cover/keyboards. The second table provides
the country codes.
NOTE: If replacing the smart card board, be sure to reinstall the smart card brackets.
Table 6-13
Top cover with keyboard descriptions and part numbers
Description Spare part number
Top cover with keyboard, backlit N17712-001
Top cover with keyboard, not backlit N17713-001
Table 6-14 Spare part country codes
For use in country or region Spare part
number
For use in country or region Spare part
number
For use in country or region Spare part
number
Belgium -A41 Hungary -211 Saudi Arabia -171
Brazil -201 Iceland -DD1 Slovenia -BA1
Top cover with keyboard (includes smart card board) 73
