Item Component Spare part number
(1) Display assembly: Non-touch display assemblies are spared at the subcomponent level only. For more non-touch display
assembly spare part information, see Display assembly subcomponents on page 18.
Full hinge-up display, touch, for models with WWAN 781955-001
Full hinge-up display, touch, for models without WWAN 798684-001
(2) Keyboard (backlit; includes keyboard cable and backlight cable):
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 46.
739563-xx1
(3) Top cover (with buttons) 781957-001
(4) ForcePad (Touchpad) 739565-001
(5) Smart Card reader (includes cable) 739566-001
(6) Fingerprint reader board (includes bracket and cable) 739567-001
(7) Speakers (includes cable) 739577-001
(8) AC power connector 749612-001
(9) Function board 739574-001
(10) Heat sink/thermal module with fans (includes replacement thermal material): 781954-001
(11) System board (includes processor and replacement thermal material):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Intel Core i7-5650U processor (2.20 GHz, 4-MB cache) 806993-xxx
Intel Core i7-5600U processor (2.60 GHz, 4-MB cache) 798520-xxx
Intel Core i7-5500U processor (2.60 GHz, 4-MB cache) 831096-xxx
Intel Core i5-5300U processor (2.30 GHz, 3-MB cache) 798519-xxx
Intel Core i5-5200U processor (2.20 GHz, 3-MB cache) 798518-xxx
(12) NFC module 781956-001
(13) Memory module (DDR3L-12800, 1600-MHz, DDR3):
NOTE: Only DDR3L memory is supported. DDR3 memory is not supported.
NOTE: Memory conguration is selected when the computer is ordered and is not upgradeable.
4-GB 747221-005
(14) Battery (6-cell, 42-Wh, 1.93-Ah, Li ion): 722297-005
(15) WLAN modules:
Intel Dual Band Wireless-AC 7265AN 802.11 a/b/g/n 2×2 WiFi + Bluetooth 4.0 WLAN module 756748-005
Intel Dual Band Wireless-N 7265 802.11 a/c 2×2 WiFi + Bluetooth 4.0 Combo Adapter 756749-005
Intel Dual Band Wireless-N 7265 802.11 a/c 2×2 WiFi + Bluetooth 4.0 Combo Adapter for use
in Indonesia
783721-005
(16) RTC battery (includes double-sided tape) 739562-001
16 Chapter 3 Illustrated parts catalog
