SSD drive
Description Spare part number
Solid-state drive
512-GB 798522-001
512-GB, TLC 835619-001
256-GB, SED, OPAL2 781964-001
256-GB, TLC 800168-001
256-GB 801976-001
180-GB 781961-001
180-GB, self-encrypting 781962-001
128-GB, TLC 800169-001
128-GB 781960-001
Before removing the hard drive, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 31).
5. Disconnect the battery (see Battery on page 36).
Remove the SSD:
1. Remove the Phillips PM2.0×3.0 screw (1) that secures the drive to the system board.
38 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
