HP EliteBook Folio 1040 G2 User Manual

9 Using Setup Utility (BIOS) in Ubuntu Linux
Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output
devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility includes
settings for the types of peripherals installed, the startup sequence of the computer, and the amount of
system and extended memory.
NOTE: Use extreme care when making changes in Setup Utility. Errors can prevent the computer from
operating properly.
Starting Setup Utility
▲
Turn on or restart the computer. While the “Press the ESC key for Startup Menu” message is displayed in
the lower-left corner of the screen, press esc. When the Startup Menu is displayed, press f10.
Using Setup Utility
Changing the language of Setup Utility
1. Start Setup Utility.
2. Use the arrow keys to select System Conguration > Language, and then press enter.
3. Use the arrow keys to select a language, and then press enter.
4. When a conrmation prompt with your language selected is displayed, press enter.
5. To save your change and exit Setup Utility, use the arrow keys to select Exit > Exit Saving Changes, and
then press enter.
Your change takes eect immediately.
Navigating and selecting in Setup Utility
Setup Utility does not support the TouchPad. Navigation and selection are by keystroke.
●
To choose a menu or a menu item, use the arrow keys.
●
To choose an item in a list or to toggle a eld—for example an Enable/Disable eld—use either the
arrow keys or f5 and f6.
●
To select an item, press enter.
●
To close a text box or return to the menu display, press esc.
●
To display additional navigation and selection information while Setup Utility is open, press f1.
Displaying system information
1. Start Setup Utility.
2. Select the Main menu. System information such as the system time and date, and identication
information about the computer is displayed.
3. To exit Setup Utility without changing any settings:
Starting Setup Utility 81

HP EliteBook Folio 1040 G2 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Memory slots	1x SO-DIMM
Memory clock speed	1600 MHz
Memory form factor	On-board + SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Display surface	Matt
Display diagonal	14 \
Native aspect ratio	16:9
On-board graphics card ID	0x1616
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 5500
Maximum on-board graphics card memory	16 GB
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	11.2
On-board graphics card dynamic frequency (max)	900 MHz
Audio system	DTS Studio Sound
Number of built-in speakers	2
Front camera signal format	720p
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
AC adapter power	45 W
Number of battery cells	6
Pointing device	Touchpad
Password protection type	Power on
Motherboard chipset	Intel SoC
Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor cache	3 MB
Processor model	i5-5300U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-5300 Mobile Series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.3 GHz
Processor cache type	L3
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Maximum number of PCI Express lanes	12
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Processor code	SR23X
Processor ARK ID	85213
Processor package size	40 x 24 x 1.3 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	233.5 mm
Width	338 mm
Height	15.9 mm
Weight	1510 g
