HP EliteBook Folio 1040 G2 User Manual

SIM slot
Description Spare part number
Plastics Kit 739575-005
The Plastics Kit includes both the SIM slot insert for use in models with WWAN and the SIM slot cover for use
in models without WWAN.
Service technicians must remove the system board to remove the SIM slot cover.
SIM slot insert (WWAN models)
The SIM slot insert, used on WWAN models, matches the size of the SIM card and is customer removable.
To insert and remove the SIM slot insert:
1. Insert with the arrow on insert visible.
2. To remove the insert, use the standard with push-pull movement.
SIM slot cover (non-WWAN models)
The SIM slot cover, used on models without WWAN, is shorter than a SIM card, notched, and is not customer
removable.
To insert and remove the SIM slot cover:
1. Insert with the arrow on insert visible.
Component replacement procedures 63

HP EliteBook Folio 1040 G2 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Memory slots	1x SO-DIMM
Memory clock speed	1600 MHz
Memory form factor	On-board + SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Display surface	Matt
Display diagonal	14 \
Native aspect ratio	16:9
On-board graphics card ID	0x1616
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 5500
Maximum on-board graphics card memory	16 GB
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	11.2
On-board graphics card dynamic frequency (max)	900 MHz
Audio system	DTS Studio Sound
Number of built-in speakers	2
Front camera signal format	720p
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
AC adapter power	45 W
Number of battery cells	6
Pointing device	Touchpad
Password protection type	Power on
Motherboard chipset	Intel SoC
Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor cache	3 MB
Processor model	i5-5300U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-5300 Mobile Series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.3 GHz
Processor cache type	L3
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Maximum number of PCI Express lanes	12
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Processor code	SR23X
Processor ARK ID	85213
Processor package size	40 x 24 x 1.3 mm
Supported instruction sets	AVX 2.0
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	233.5 mm
Width	338 mm
Height	15.9 mm
Weight	1510 g
