ForcePad (Touchpad)
Description Spare part number
ForcePad (Touchpad) (includes cable) 739565-001
Before removing the ForcePad, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 31).
5. Remove the battery (see Battery on page 36).
Remove the ForcePad:
1. Disconnect the ForcePad cable (1) and the NFC module cable (2) from the connectors on the ForcePad.
2. Remove the cables from under the Mylar that secures them (3).
Component replacement procedures 49
