Battery
Description Spare part number
6-cell, 42-Wh, 1.93-Ah, Li ion battery 722297-005
Before disassembling the computer, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 31).
Remove the battery:
1. Disconnect the battery cable from the system board (1).
2. Remove the six Phillips PM2.0×4.0 screws (2) that secure the battery to the computer.
36 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
