2. Pry up on the top (near the display hinge) of the bottom cover to disengage it from the computer.
Reverse the removal procedures to install the bottom cover.
When reinstalling the bottom cover, install the screws in the sequence as illustrated in the following image.
IMPORTANT: To prevent rocking, be sure to use the correct sequence when installing the screws.
32 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
