HP elitedisplay e230t User Manual

Front bezel controls
Control Function
1 Menu button Opens and closes the OSD menu.
NOTE: To activate the Menu button and the Function buttons, press any of the buttons
so that the button labels appear on the screen.
2 Function buttons Use these buttons to navigate through the OSD menu based on the indicators next to the
buttons that are activated while the OSD menu is open.
NOTE: You can recongure the Function buttons in the OSD menu to quickly select the
most commonly used operations. See Assigning the Function buttons on page 18 for
more information.
3 Power button Turns the monitor on or o.
NOTE: To view an OSD menu simulator, visit the HP Customer Self Repair Services Media Library at
http://www.hp.com/go/sml.
4 Chapter 1 Getting Started

HP elitedisplay e230t Specifications

General

Color gamut	72 %
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Backlight type	W-LED
Glossy display	No
Display diagonal	23 \
Touch technology	Multi-touch
Touchscreen type	Table
Display brightness	250 cd/m²
Display technology	LED
Touchscreen technology	Capacitive
Contrast ratio (dynamic)	500000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	58.42 cm
Number of simultaneous touchpoints	10
Product color	Black, Silver
Country of origin	China
Placement supported	Horizontal
Display viewable area (HxV)	509.184 x 286.416 mm
Dimensions (W x D x H) with stand	520.8 x 189 x 486.6 mm
Cables included	AC, USB, VGA
Tilt angle range	-5 - 25 °
Height adjustment	150 mm
Power supply type	AC
Power consumption (max)	57 W
Power consumption (standby)	0.5 W
Power consumption (typical)	29 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	2
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	189 mm
Width (with stand)	520.8 mm
Height (with stand)	486.6 mm
Weight (with stand)	4900 g
Depth (without stand)	52.3 mm
Height (without stand)	311.95 mm
