HP elitedisplay e230t User Manual

Product features and components
Features
The monitor features include the following:
●
58.4 cm (23-inch) diagonal viewable screen area with 1920 x 1080 resolution, plus full-screen support
for lower resolutions; includes custom scaling for maximum image size while preserving original aspect
ratio
●
Nonglare panel with an LED backlight
●
Wide viewing angle to allow viewing from a sitting or standing position, or when moving from side to
side
●
Tilt capability
●
Pivot capability to rotate the display head from landscape to portrait mode
●
Swivel and height adjustment capabilities
●
Removable stand for exible display head mounting solutions
●
DisplayPort and VGA video inputs (cables provided)
●
One HDMI (High-Denition Multimedia Interface) video input (cable not provided)
●
USB 3.0 hub with one upstream port (connects to the computer) and two downstream ports (connects to
USB devices)
●
USB cable provided to connect the monitor's USB hub to the USB connector on the computer
●
Plug-and-play capability if supported by your operating system
●
Security cable slot provision on rear of monitor for optional security cable
●
On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
●
HP Display Assistant software for adjusting monitor settings and enabling the theft deterrence features
●
HDCP (High-Bandwidth Digital Content Protection) copy protection on all digital inputs
●
Software and documentation optical disc provided with the monitor in select regions that includes
monitor drivers and product documentation
●
Energy saver feature to meet requirements for reduced power consumption
NOTE: For safety and regulatory information, refer to the Product Notices provided on your optical disc or in
your documentation kit. To locate updates to the user guide for your product, go to http://www.hp.com/
support, and select your country. Select Find your product, and then follow the on-screen instructions.
2 Chapter 1 Getting Started

HP elitedisplay e230t Specifications

General

Color gamut	72 %
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Backlight type	W-LED
Glossy display	No
Display diagonal	23 \
Touch technology	Multi-touch
Touchscreen type	Table
Display brightness	250 cd/m²
Display technology	LED
Touchscreen technology	Capacitive
Contrast ratio (dynamic)	500000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	58.42 cm
Number of simultaneous touchpoints	10
Product color	Black, Silver
Country of origin	China
Placement supported	Horizontal
Display viewable area (HxV)	509.184 x 286.416 mm
Dimensions (W x D x H) with stand	520.8 x 189 x 486.6 mm
Cables included	AC, USB, VGA
Tilt angle range	-5 - 25 °
Height adjustment	150 mm
Power supply type	AC
Power consumption (max)	57 W
Power consumption (standby)	0.5 W
Power consumption (typical)	29 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	2
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	189 mm
Width (with stand)	520.8 mm
Height (with stand)	486.6 mm
Weight (with stand)	4900 g
Depth (without stand)	52.3 mm
Height (without stand)	311.95 mm
